Pravin Electronics & Electricals

Kusum-Meco KM 525 AC + DC True RMS Multi Parameter Mobile Logger Digital Multimeter With PC Interface

Kusum-Meco KM 525 AC + DC True RMS Multi Parameter Mobile Logger Digital Multimeter With PC Interface
Product Catalogue
Special Features
  • Stand Alone Multi Parameter Logging
  • Record Max/Min/ MAX-MIN readings
  • Audible and visible input warning
  • Auto -ranging relative zero mode
  • AutoCheck V & Auto-ranging 50ms record
  • T1-T2 Differntial temperature readings
  • NCV & Probe contact EF Detection
  • nS conductance
  • Lo-Z volts to drain Ghost Voltages (Autocheck feature)
  • Logic & Line level frequancy
  • Logiv Level duty cycle readings

AC; AC + DC True RMS Multi Parameter Mobile Logger Digital Multimeter With PC Interface

MODEL KM 525 (17 Functions 69 Ranges)

KM 525 Stand Alone logging capability 43500 / 87000 points for dual / single display with selectable logged interval 0.05s, 0.1s, 1s, 2s, 3s, 4s, 5s, 10s, 15s, 30s, 60s, 120s, 180s, 300s, 600s

General Specifications
  • Sensing : AC, AC+DC True RMS
  • Display :
    9999 Counts : ACV, DCV, Hz & nS
    6000 Counts : mV, µA, mA, A, Ohm & Capacitance
  • Update Rate : Digital Display : 5 per second nominal;
    41 Segments Bar-graph : 60 per second max
  • Low Battery : Below approx 7V
  • Operating Temperature : 0 °C to 45 °C
  • Relative Humidity : Maximum 80% R.H.
    For Temperature up to 31 °C decreasing linearly to 50% R.H. at 45 °C
  • Storage Temperature: -20 °C to 60 °C,<80% R.H. (with battery removed)
  • Altitude : Operating below 2000m
  • Temperature Coefficient : nominal 0.15 x (specified accuracy)/°C @ (0 °C ~ 18 °C or 28 °C ~ 45 °C), or otherwise specified
  • Power Consumption : 5mA typical
  • APO Timing : Idle for 30 minutes
  • APO Consumption : 50μA typical
  • Power Supply : Single 9V battery
  • Dimension : 208(L) x 103(W) x 64.5(H) mm
  • Weight : Approx. 635gm with holster
